DX-050
1 to 1 DVI CAT.5 KVM Extender
1 to 1 DVI CAT.5 KVM Extender
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
- Long distance transmission – up to 50m
- Uses Cat 5e cable to connect the local and remote units
- Features UNICLASS EDID technology that allows transmission over Cat 5e cable
- Superior video quality –up to 1920x1200 (40m); 1080p (40m); 1080i (50m)
- Stereo Audio enabled
- Adjustable EQ compensation control
- Supports widescreen formats
- Extends the distance between DVI source and DVI display device
- Support Hot plug Detect
- USB Keyboard and USB Mouse Ports
- USB Device Port
Description
- Description
- Specification
- Download
The DX-050 DVI USB KVM Extender with Audio extends your DVI display up to 50m away from your DVI source using Cat 5e cables. The use of Cat 5e cables provides a simple and reliable connection method that takes advantage of the wiring system in most modern office buildings. The DX-050 incorporates UNICLASS’s technology that allows the Audio KVM signal to be transmitted over Cat 5e cable. If the real EDID is required, simply goes through the Cat 5e cable. With stereo audio support and include for popular widescreen formats (resolution up to 1920 x 1200), the DX-050 provides crystal-clear image and sound quality in all installations where remote DVI displays are required.
