RH-1080AR
8-Port 4K Rack-mountable HDMI 2.0 KVM Switch w/ Audio, USB 2.0 Hub, and RS-232
8-Port 4K Rack-mountable HDMI 2.0 KVM Switch w/ Audio, USB 2.0 Hub, and RS-232
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
- 8-port Rack-mountable HDMI 2.0 KVM Switch w/ Audio, USB 2.0 Hub, and RS-232
- Source to End HDMI video interface
- Unique HDMI/Audio/USB-Hub interface for multimedia needs
- Includes Rack Mount Kit for easy installation into server rack cabinet
- 2 extra USB device ports for high-speed USB 2.0 device sharing
- Independent peripheral switching configurable by hotkeys
- Simultaneous/independent switching of PC/USB hub/audio port selection
- RS-232 Serial Control
- Supports digital video resolution up to 3840 x 2160 4K@60Hz
- Supports Windows 7/10/11, Linux and Mac OS X
- Multi-platform support PCs and Macintosh
- Status LED display for easy port status monitoring
- Buzzer sound for port switching confirmation
- Metal enclosure for best shielding and protection
- Firmware upgradable via USB port
- HDMI 2.0/1.4 Specification compliant
- HDMI 2.0 technology supports High Quality Digital Video
Description
- Description
- Specification
- Download
RH-1080AR DATASHEET
(2024/06/21 14:00:53)
RM 1K4K KVM Comparison Table
(2024/06/21 14:00:53)
