4-port DVI Video Splitter
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
▪ 4-port DVI Video Splitter
▪ DVI Single Link technology supports digital video signal transmission
▪ DDC2B Emulation
▪ Control 4 DVI monitors/Flat Panel Displays to display the same video output source from a PC
▪ Daisy-chain support up to 3 levels for scalable monitor port capacity
▪ Support up to 100 DVI monitors/Flat Panel Displays with multiple daisy-chained units
▪ Enhance video signal with DVI video cable distance up to 20 meters (15m+5m, per cascade level)
▪ Video bandwidth up to 165 MHz (digital)
▪ Resolution support up to 1920 x 1200 (digital)
▪ Simultaneous monitor display
▪ Power LED indicator for power status monitoring
▪ Plug-and-play, no extra software needed
- Description
- Specification
- Download
The UDS-004T is a TMDS-compliant 4-port DVI Video Splitter that allows four DVI monitors to display the same video source from a single PC. The UDS-004T supports digital video (1920 x 1200) for your maximum convenience in adapting to your display requirements. It offers a digital video bandwidth of up to 165 MHz (digital) that supports up to 1920 x 1200 (digital). While splitting the video signals to multiple DVI monitors/Flat Panel Displays, the image quality is not in the least degraded and stays crisp and clear throughout. For more DVI monitors, you can drive up to 100 monitors by cascading multiple DVI Video Splitters together. The DVI Video Splitters are your ideal solution for
showroom and classroom presentation.
