AI-232A
2-port HDMI 2.0 KVM Switch w/USB 3.0 Hub
2-port HDMI 2.0 KVM Switch w/USB 3.0 Hub
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
- 2-port HDMI USB KVM switch with audio and microphone switching and 2 x USB 3.0 hub ports
- HDMI2.0/ 1.4 Specification compliant
- Source to End DP/HDMI video interface
- Unique DP/HDMI/Audio/Mic/USB-Hub interface for multimedia needs
- True Transparent USB (TTU) Emulation Technology with an integrated ASIC
- USB3.0/ USB 2.0/ USB1.1 Specification compliant
- HDCP specifications complaint
- Support digital video resolution up to 3840 x 2160@60HZ
- Support Windows XP/7/10, Linux and Mac OS
- Multi-platform support for PCs and Macintosh
- 2 x USB 3.0 device ports for sharing high-speed USB devices
- Independent/ simultaneous PC/ hub/ audio & mic port selection
- Independent peripheral switching configurable by hotkeys or 2/4 push buttons
- Firmware upgradable via USB port
- HDMI technology supports High Quality Digital Vide
- Status LED display for easy port status monitoring
- Buzzer sound for port switching confirmation
- Metal enclosure for best shielding and protection
Description
- Description
- Specification
- Download
AI-232A DATASHEET
(2025/02/19 15:13:18)
Desktop KVM Switch Comparison
(2025/02/19 15:13:18)
